Cross Cutter Double

The Cross Cutter Double is designed to create bandsaw effects on wood surfaces. By adjusting the throughput speed, abrasive belt speed, angle settings of the abrasive belt unit, pressure on the workpiece surface, and the type of abrasive belt, the machine offers great flexibility to achieve the desired effect.

This version features two Cross Cut units, allowing for deeper bandsaw texture. It also enables the use of different abrasive belt types in a single pass and the option to experiment with overlapping sanding directions. These features further enhance the machine’s versatility and the range of effects it can produce.

Cross Cutter Double

For creating a natural deep bandsaw effect on parquet flooring and planks for wall finishing. The technique is used for aging effects in combination with a reactive- or color stain.

  • Parquet flooring.
  • Exterior wood.
  • Furniture panels.
  • Stair steps.
  • Kitchen cabinets.
  • Other similar workpieces.
  • Aging Wooden Surfaces.
  • Equipped with the Trivec Tapper System; multiple pneumatic shoes push down each Cross cutter belt at random intervals to create unique effects.
  • Equipped with two Cross cutter units.
  • Height adjustment.
  • Integrated high-grip conveyor for consistent results.
  • Pressure rollers on each unit for consistent results.
  • Can be equipped with various Cross cutter belts.
  • Quick change system for the Cross cutter belts.
  • Working width max: 400 mm
  • Minimal workpiece length: 300 mm
  • Working height: 900 mm (+20/-20 mm)
  • Throughput height: 4 – 250 mm
  • Throughput speed: 4 – 15 m/min
  • Ø Exhaust connection: 1 x 80 mm
  • Control: via touchscreen
  • Compressed air requirements: minimum of 6 bar
  • Pressure rollers: one before and one after the cross cutter belt
  • Marking: CE (UL optional)

The Result

View the results achieved with the Cross Cutter Double.

Compatibility & Integration

Compatibility and Future-Proof Integration

The Cross Cutter Double is designed to integrate seamlessly with Trivec systems and a wide range of equipment from other manufacturers, including sanding units, conveyors, and finishing stations. Its adaptable nature simplifies customization and allows for effortless expansion of production workflows. With a scalable design, it can be easily incorporated into larger production setups without requiring modifications. As a dependable and future-ready solution, the Cross Cutter enhances operational efficiency and evolves to meet the demands of growing businesses.

Safe and Efficient Line Connection

The Cross Cutter Double includes a control cabinet with built-in connections for emergency stop and error notifications, ensuring seamless and secure integration into production lines of any scale or complexity. With a focus on operational safety and minimized downtime, this system provides dependable, uninterrupted performance, maximizing efficiency across the entire production process.

Compatibility for Diverse Production Needs

The Cross Cutter Double delivers exceptional versatility, making it ideal for diverse production environments. Its adaptability stems from compatibility with a variety of cross cutter belts and brush types, including sanding, abrasive, and specialized brushes. This ensures seamless customization to meet the specific needs of different materials and applications, enabling a wide range of surface effects.
